Manual | MNS-SG Operation and Maintenance 7
1.3. Technical data table
Standards
Type-tested switchgear
assemblies (TTA)*
ANSI C37.20.1, ANSI C37.20.7, ANSI C37.50, ANSI
C37.51, ASCE/SEI 7-05, CSA C22.2 No. 31, IEEE
1584, UL 50 E, UL1558, UL508
Test certificates
The MNS-SG is designed, tested and
constructed in accordance with the
following industry standards and
guidelines:
UL file E235182
Electrical data
Rated voltages
Rated insulation voltage Vi
2.2 kV
Rated operating voltage Ve
240, 480 or 600 VAC
System types
3 phase-3 wire, 3 phase-4 wire
Rated Frequency
50/60 Hz
Rated ampacities main and
distribution busbars
Rated current
1,600A up to 5,000A
Rated short circuit current
Up to 100kA @ 600V
Mechanical features
Dimensions
Height: in (mm)
90.6 (2,300) [without chimney, plenum or top hat]
Width: in (mm)
23.6 (600) 27.6 (700) 31.5 (800) 39.4 (1,000) 19.7
(500) transition section
Depth: in (mm)
72.9 (1,852) 80.8 (2052)
Basic unit (grid) size
E = approximately 1.0 inch (25 mm)
Surface protection
Frame
Alu-zinc coated/galvanized/stainless steel
Internal subdivision
Alu-zinc coated/galvanized/stainless steel
Transverse section
Galvanized
Enclosure
Paint color gray ANSI 61 hammered tone
Enclosure type
NEMA 1 (arc-resistant)
NEMA 1 with gasketing (non arc-resistant)
Plastic components
Self-extinguishing, flame retardant
Busbars
Standard - silver plated, tin-plated (copper available)
Bus bracing
Up to 100kA @ 600V
Paint finish
Enclosure
Standard - textured ANSI 61
Special colors available)
* TTA: Switchgear assembly corresponding to the original type or system
of switchgear assembly type tested in accordance with these standards.
