7.20.1 Table Application settings
Recommended basic setting
Start ramp time
Stop ramp time
Start ramp initial level
Stop ramp end level
Current limit level
Start mode
Stop mode
Normal start (class 10)
Band saw 10 - 30 30 4 Voltage ramp No ramp
Bow thruster 10 - 30 30 3 Voltage ramp No ramp
Centrifugal pump 10 10 30 30 4 Voltage ramp Torque ramp
Circular saw 10 - 30 30 4 Voltage ramp No ramp
Conveyor belt short 10 - 40 30 3,5 Voltage ramp No ramp
Cutter 10 - 30 30 4 Voltage ramp No ramp
Escalator 10 - 30 30 3,5 Voltage ramp No ramp
High pressure pump 10 10 40 30 4,5 Voltage ramp Torque ramp
Hydraulic pump 10 - 30 30 3 Voltage ramp No ramp
Lift/Elevator 10 - 30 30 3,5 Voltage ramp No ramp
Piston compressor 5 - 50 30 3 Voltage ramp No ramp
Scroll compressor 2 - 50 30 3 Voltage ramp No ramp
Heavy duty start (class 30)
Axial fan 10 - 30 30 4 Voltage ramp No ramp
Conveyor belt long 10 - 40 30 3,5 Voltage ramp No ramp
Crusher 10 - 30 30 4 Voltage ramp No ramp
Centrifugal fan 10 - 30
30 4 Voltage ramp No ramp
Grinder 10 - 30 30 4 Voltage ramp No ramp
Mixer 10 - 30 30 3,5 Voltage ramp No ramp
Note: Use the parameter values above as guidance only.
Additional tuning can be necessary because of variations
in load conditions.
