31
EN
Inverter
PVS-100-TL PVS-120-TL
Environmental
Ambient temperature range -25...+60°C /-13...140°F with derating above 40°C / 104 °F
Storage temperature -40°C...+85°C / -40°F...185°F
Relative humidity 4…100 % with condensation
Sound pressure level, typical 68dB(A) @ 1m
Maximum operating altitude without derating 2000 m / 6560 ft
Environmental pollution degree classification for external en-
vironments
3
Environmental class Outdoor
Climatic category according to IEC 60721-3-4 4K4H
Physical
Environmental protection rating IP 66 (IP54 for cooling section)
Cooling Forced air
Dimension (H x W x D) 869x1086x419 mm / 34.2” x 42.8” x 16.5”
Weight
70kg / 154 lbs for power module ; ~55kg / 121 lbs for wiring box
Overall max 125 kg / 276 lbs
Mounting system Mounting bracket vertical & horizontal support
Overvoltage rating as per IEC 62109-1 II (DC input) III (AC output)
Safety
Safety class I
Isolation level Transformerless
Marking & EMC CE conformity according to LV and EMC directives
Safety IEC/EN 62109-1, IEC/EN 62109-2
Grid standard (check your sales channel for availability)
CEI 0-16, CEI 0-21, IEC 61727, IEC 62116, IEC 60068, IEC 61683, JOR-
DAN IRR-DCC-MV, AS/NZS4777.2, VDE-AR-N 4105, VDE V 0-126-1-1,
VFR 2014, Belg C10-C11, UK59/3, P.O. 12.3, ITC-BT-40,
EN50438 Generic +Ireland, CLC-TS 50549-1/2
Accessories
Assembly accessories
- PVS Installation Kit
- AC multicore cable gland plate
(Supports M63 Ø 37…53mm + M25 Ø 10...17mm)
1. Maximum number of opening 5 under overloading
2. Please refer to the document “String inverters – Product manual appendix” available at www.abb.com/solarinverters for informa-
tion on the quick-fit connector brand and model used in the inverter
3. Maximum fuse size supported 20A. Additionally two strings input per MPPT supports 30A fuse size for connecting two strings
per input.
4. The AC voltage range may vary depending on specific country grid standard
5. Frequency range may vary depending on specific country grid standard
6. In the event of a fault, limited by the external protection envisaged on the AC circuit
Remark. Features not specifically listed in the present data sheet are not included in the product
