ABB PVS-100-TL User Manual

30
EN
Inverter
PVS-100-TL PVS-120-TL
Input side
Absolute maximum DC input voltage (Vmax,abs) 1000V
Start-up DC input voltage (Vstart) 420V (400…500 V)
Operating DC input voltage range (Vdcmin...Vdcmax) 360…1000 V
Rated DC input voltage (Vdcr) 620V 720V
Rated DC input power (Pdcr) 102 000W 123 000W
Number of independent MPPT 6
MPPT input DC voltage range at (VMPPTmin...VMPPTmax) at
Pacr
480…850V 570…850V
Maximum DC input power for each MPPT (PMPPT,max) 17500 W [480V≤VMPPT≤850V 20500 W [570V≤VMPPT≤850V
Maximum DC input current for each MPPT (Idcmax) 36 A
Maximum input short circuit current (Iscmax) for each MPPT 50 A
1)
Maximum Return current (AC side vs DC side)
Negligible in normal operating conditions
(6)
Number of DC input connection pairs for each MPPT 4
DC connection type PV quick fit connector
(2)
Type of photovoltaic panels that can be connected at input
according to IEC 61730
Class A
Input protection
Reverse polarity protection Yes, from current limited source
Input over voltage protection for each MPPT - replaceable
surge arrester board
Type II with monitoring only for SX and SX2 versions;
Type I+II with monitoring only for SY and SY2 versions
Photovoltaic array isolation control as per IEC62109
DC switch rating for each MPPT 50 A / 1000 V
Fuse rating (versions with fuses) 15 A / 1000 V
3)
String current monitoring
SX2, SY2: (24 input string) Individual string current monitoring;
SX, SY: (6ch) Input current monitoring per MPPT
Output side
AC grid connection type Three phase 3W+PE or 4W+PE
Rated AC power (Pacr @cosφ=1) 100 000 W 120 000 W
Maximum AC output power (Pacmax @cosφ=1) 100 000 W 120 000 W
Maximum apparent power (Smax) 100 000 VA 120 000 VA
Rated AC grid voltage (Vac,r) 400 V 480 V
AC voltage range 320...480 V
4)
384...576
4)
Maximum AC output current (Iac,max) 145 A
Contributory fault current 155 A
Inrush current Negligible
Rated output frequency (fr) 50 Hz / 60 Hz
Output frequency range (fmin...fmax) 45...55 Hz / 55…65 Hz
5)
Nominal power factor and adjustable range > 0.995, adj. ± 0 - 1 (over/under exited)
Total current harmonic distortion <3%
Maximum AC cable 185mm
2
Aluminum and copper
AC connections type
Provided bar for lug connections M10, single core cable glands
4xM40 and M25, multi core cable gland M63 as option
Output protection
Anti-islanding protection
Active frequency drift combined with RoCoF techniques
as per IEC 62116
Maximum external AC overcurrent protection 225 A
Output overvoltage protection - replaceable surge protection
device
Type 2 with monitoring
Operating performance
Maximum efficiency (ηmax) 98.4% 98.9%
Weighted efficiency (EURO) 98.2% 98.6%
Communication
Embedded communication interfaces 1x RS-485, 2x Ethernet (RJ45), WLAN (IEEE802.11 b/g/n @ 2,4 GHz)
User interface 4 LEDs, Web User Interface, Mobile APP
Communication protocol Modbus RTU/TCP (Sunspec compliant)
Commissioning tool Web User Interface, Mobile APP/APP for plant level
Remote monitoring services Aurora Vision® monitoring portal
Advanced features Embedded logging, direct telemetry data transferring to ABB cloud
—
Characteristics and technical data
