Introduction to the manual 19
Quick installation, commissioning and operation
flowchart
Task Refer to
Plan the installation.
Do a check of the ambient conditions, ratings, required
cooling air flow, input and output power connection,
compatibility with the solar generator and other technical
data.
Select the cables.
Technical data and Planning the electrical
installation in the PVS800-57B central inverters
hardware manual (3AXD50000048300 [EN])
Option manual (if optional equipment is included)
Unpack and examine the units for damage.
Make sure that all of the optional modules and
equipment are present and correct.
Storing, lifting and transporting (page 23).
Examine the installation site. Examining the installation site (page 30)
Route the cables. Routing the cables (page 40)
Install the inverter. Connect the power cables.
Connect the control and the auxiliary control cables.
Mechanical installation (page 29)
Electrical installation (page 39)
Make sure that the installation is correct. Installation checklist (page 51)
