Mount the angled frame to the cut-out in the panel with four screws.
The recommended panel thickness is 2 mm at the minimum.
5
40,5
5,5
203
+1
-1
177
+0,2
-0,2
167
+1
-1
122
+0,2
-0,2
A051484
Fig. 4.5.-2 Panel cut-out dimensions
A051486
Fig. 4.5.-3 Relay (angled frame, case and plug-in unit) mounted in a 25° angle
