25
149.3
30.8
A040173
Fig. 4.6.-2 Relay (case and plug-in unit) rack mounted
4.7. Wall mounting
The wall mounting kit (for order numbers, refer to Chapter 6. Accessories)
allows you to mount the relay on a wall (projection mounting). The mounting
kit contains:
*
Two two-piece mounting brackets (frame and rail parts). The mounting
brackets are made of steel sheet (light grey, Pantone 420).
*
Back plate
*
Screws
*
Detailed mounting instructions
*
Dimensions for screw holes
When connecting the wires, a wall-mounted relay can be pulled out 160 mm
and turned 45 (or 90) degrees downwards (or upwards). The part in item "A"
in Fig. 4.7.-1 and in Fig. 4.7.-2 locks the relay to selected (pushed-in or
pulled-out) position. Release the relay by pushing the locks.
1MRS752265-MUM
Protection Relay
Installation Manual
RE_ 610
