Main Menu
Parameter Menus
SETTINGS
CONFIGURATION
MEASUREMENTS
RECORDED DATA
REM 610
RTD MODULE
INFO
xxxxxxxx
YYYYMMDD
CPU MODULE
INFO
1MRS118511 A
INFO
1MRS118514 A
xxxxxxxx
xxx
xxxxxxxx
INFO
xxx
INFO INFO
Cancel
A040252_2
Fig. 4.2.1.4.-1 INFO menu group
1) Relay serial number
2) CPU module software number and revision
3) CPU module serial number
4) CPU module software build number
5) Communication module software number and revision
6) Communication module serial number
7) Communication module software build number
4.2.2. Technical level
4.2.2.1. Menu system of parameters
Press an arrow button to activate the main menu. If the default password is in use,
no password is required to change the parameters. If the password protection is in
use, "***" is shown on the display until you give the valid HMI password.
The views are used for reading and setting parameters, which are divided into two
main groups:
*
SETTINGS
*
CONFIGURATION
4.2.2.2. How to change settings
The actual settings consist of the settings of group 1 or group 2, depending on which
group has been selected to be active (indicated by an asterisk "*"). The actual
settings can be seen in the first parameter menu, for example:
30
REM 610REM 610
Motor Protection Relay
Operator's Manual - ANSI ve rsion
1MRS755538
