Table 186. Control functions
Function Function
identication
Ordering no Position Available
qty
Selected
Qty
Notes and rules
Synchrocheck, energizing check and synchronizing SESRSYN 1MRK005917-AC 1 0-2 Can only be ordered
with Apparatus
control APC10/
APC15
Synchrocheck, energizing check and synchronizing SESRSYN 1MRK005917-XD 2 0-6 Can only be ordered
with Apparatus
control APC30
Autorecloser SMBRREC 1MRK005917-BC 3 0-4 Can only be ordered
with Apparatus
control APC10/
APC15
Autorecloser SMBRREC 1MRK005917-XE 4 0-6 Can only be ordered
with Apparatus
control APC30
Control functionality for a single bay, max 10 objects (1CB),
including interlocking
APC10 1MRK005917-AZ 5 1 Only one of APC10,
APC15 or APC30
must be ordered.
Control functionality for a single bay, max 15 objects (2CB),
including interlocking
APC15 1MRK005917-BZ 6 1
Control functionality for up to 6 bays, max 30 objects (6CBs),
including interlocking
APC30 1MRK005917-CZ 7 1
Automatic voltage control for tapchanger, single control TR1ATCC 1MRK005917-NC 8 0-4 Only one ATCC
may be selected.
If TR1ATCC or
TR8ATCC is
ordered then one of
TCMYLTC or
TCLYLTC must be
ordered.
Automatic voltage control for tapchanger, parallel control TR8ATCC 1MRK005917-PC 9 0-4
Tap changer control and supervision, 6 binary inputs TCMYLTC 1MRK005917-DB 10 0-4
Tap changer control and supervision, 32 binary inputs TCLYLTC 1MRK005917-EA 11 0-4
Table 187. Scheme communication
Position
1 2 3 4 5 6 7 8
K 0 0 0
Table 188. Scheme communication functions
Function
Function
identication
Ordering no Position Available
qty
Selected
qty
Notes and rules
Scheme communication logic with delta based blocking scheme
signal transmit
ZCPSCH 1MRK005920-AA 1 0-1
Current reversal and weak-end infeed logic for distance protection ZCRWPSCH 1MRK005920-CA 3 0-1
Local acceleration logic ZCLCPSCH 1MRK005920-EA 5 0-1
Scheme communication logic for residual overcurrent protection ECPSCH 1MRK005920-FA 6 0-1
Current reversal and weak-end infeed logic for residual
overcurrent protection
ECRWPSCH 1MRK005920-GA 7 0-1
Table 189. Logic
Position
1 2 3
L 00
Table 190. Logic functions
Function
Function
identication
Ordering no Position Available
qty
Selected
qty
Notes and rules
Configurable logic blocks Q/T 1MRK005922-MX 1 0-1
Extension logic package 1MRK005922-AZ 2 0-1
Table 191. Monitoring
Position
1 2 3
M
1MRK 511 404-BEN A
Bay control REC670 2.2
Product version: 2.2.1
ABB 119
