ABB rec670 Product Guide

Control and monitoring functions
GUID-E3777F16-0B76-4157-A3BF-0B6B978863DE v15
IEC 61850 or
function name
ANSI Function description Bay control
REC670
(Customized)
REC670 (A30)
REC670 (B30)
REC670 (C30) REC670 (D30)
Control
SESRSYN 25 Synchrocheck, energizing check and synchronizing 0-6 1 2 3 1
SMBRREC 79 Autorecloser 0-6 1-H04 2-H05 3-H06 1-H04
APC10 3 Control functionality for a single bay, max 10 objects
(1CB), including interlocking (see Table 3)
0-1 1 1
APC15 3 Control functionality for a single bay, max 15 objects
(2CB), including interlocking (see Table 4)
0-1 1
APC30 3 Control functionality for up to 6 bays, max 30 objects
(6CBs), including interlocking (see Table 5)
0-1 1
QCBAY Bay control 1+5/APC30 1 1 1+5/
APC30
1
LOCREM Handling of LR-switch positions 1+5/APC30 1 1 1+5/
APC30
1
LOCREMCTRL LHMI control of PSTO 1 1 1 1 1
SXCBR Circuit breaker 18 3 6 18 3
TR1ATCC 90 Automatic voltage control for tap changer, single control 0-4 1-H11 1-H11 2-H16 1-H11
TR8ATCC 90 Automatic voltage control for tap changer, parallel
control
0-4 1-H15 1-H15 2-H18 1-H15
TCMYLTC 84 Tap changer control and supervision, 6 binary inputs 0-4 4 4 4 4
TCLYLTC 84 Tap changer control and supervision, 32 binary inputs 0-4 4 4 4 4
SLGAPC Logic rotating switch for function selection and LHMI
presentation
15 15 15 15 15
VSGAPC Selector mini switch 30 30 30 30 30
DPGAPC Generic communication function for Double Point
indication
16 16 16 16 16
SPC8GAPC Single point generic control function 8 signals 5 5 5 5 5
AUTOBITS Automation bits, command function for DNP3.0 3 3 3 3 3
SINGLECMD Single command, 16 signals 4 4 4 4 4
I103CMD Function commands for IEC 60870-5-103 1 1 1 1 1
I103GENCMD Function commands generic for IEC 60870-5-103 50 50 50 50 50
I103POSCMD IED commands with position and select for IEC
60870-5-103
50 50 50 50 50
I103POSCMDV IED direct commands with position for IEC 60870-5-103 50 50 50 50 50
I103IEDCMD IED commands for IEC 60870-5-103 1 1 1 1 1
I103USRCMD Function commands user defined for IEC 60870-5-103 4 4 4 4 4
Secondary system
supervision
1MRK 511 404-BEN A
Bay control REC670 2.2
Product version: 2.2.1
