ABB rec670 Product Guide

Table 5. Number of function instances in APC30
Function name Function description Total number of instances
SCILO Interlocking 30
BB_ES 6
A1A2_BS 4
A1A2_DC 6
ABC_BC 2
BH_CONN 2
BH_LINE_A 2
BH_LINE_B 2
DB_BUS_A 3
DB_BUS_B 3
DB_LINE 3
ABC_LINE 6
AB_TRAFO 4
SCSWI Switch controller 30
SXSWI Circuit switch 24
QCRSV Apparatus control 6
RESIN1 1
RESIN2 59
POS_EVAL Evaluation of position indication 30
QCBAY Bay control 5
LOCREM Handling of LR-switch positions 5
XLNPROXY Proxy for signals from switching device via
GOOSE
42
GOOSEXLNRCV GOOSE function block to receive a switching
device
42
Table 6. Total number of instances for congurable logic blocks Q/T
Congurable logic blocks Q/T
Total number of instances
ANDQT 120
INDCOMBSPQT 20
INDEXTSPQT 20
INVALIDQT 22
INVERTERQT 120
ORQT 120
PULSETIMERQT 40
RSMEMORYQT 40
SRMEMORYQT 40
TIMERSETQT 40
XORQT 40
1MRK 511 404-BEN A
Bay control REC670 2.2
Product version: 2.2.1
ABB 17
