ABB RED670 Product Guide

Station communication
Table 149. Communication protocols
Function Value
Protocol IEC 61850-8-1
Communication speed for the IEDs 100BASE-FX
Protocol IEC 60870–5–103
Communication speed for the IEDs 9600 or 19200 Bd
Protocol DNP3.0
Communication speed for the IEDs 300–19200 Bd
Protocol TCP/IP, Ethernet
Communication speed for the IEDs 100 Mbit/s
Table 150. IEC 61850-9-2 communication protocol
Function
Value
Protocol IEC 61850-9-2
Communication speed for the IEDs 100BASE-FX
Table 151. LON communication protocol
Function
Value
Protocol LON
Communication speed 1.25 Mbit/s
Table 152. SPA communication protocol
Function
Value
Protocol SPA
Communication speed 300, 1200, 2400, 4800, 9600, 19200 or 38400 Bd
Slave number 1 to 899
Table 153. IEC 60870-5-103 communication protocol
Function
Value
Protocol IEC 60870-5-103
Communication speed 9600, 19200 Bd
Table 154. SLM – LON port
Quantity
Range or value
Optical connector Glass fiber: type ST
Plastic fiber: type HFBR snap-in
Fiber, optical budget Glass fiber: 11 dB (1000m/3000 ft typically *)
Plastic fiber: 7 dB (10m/35ft typically *)
Fiber diameter
Glass fiber: 62.5/125 mm
Plastic fiber: 1 mm
*) depending on optical budget calculation
1MRK 505 346-BEN -
Line differential protection RED670 2.1 IEC
Product version: 2.1
ABB 105

ABB RED670 Specifications

General

Rated Frequency	50/60 Hz
Product Type	Protection Relay
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, IEC 60870-5-103, DNP3
Operating Temperature Range	-25°C to +55°C
Protection Functions	Differential protection, distance protection, overcurrent protection
Outputs	Binary outputs
Enclosure	IP54
Mounting	19" rack mounting
