ABB RED670 - Human Machine Interface Selection; Connection Type for Input;Output Modules; Connection Type for Power Supply Module; Mounting Selection

Table 209. Mounting selection
Mounting details with IP40 of protection from the front Selection Notes and Rules
No mounting kit included X
19" rack mounting kit for 1/2 x 19" case of 2xRHGS6 or RHGS12 A
19" rack mounting kit for 3/4 x 19" case or 3xRGHS6 B
19" rack mounting kit for 1/1 x 19" case C
Wall mounting kit D Note: Wall mounting not
recommended with
communication modules with fibre
connection (SLM, OEM, LDCM)
Flush mounting kit E
Flush mounting kit + IP54 mounting seal F
Selected
Table 210. Connection type for Power supply module
Selection Notes and Rules
Compression terminals M
Ringlug terminals N
Auxiliary power supply
Power supply module 24-60 VDC A
Power supply module 90-250 VDC B
Selected
Table 211. Connection type for Input/Output modules
Selection Notes and Rules
Compression terminals P
Ringlug terminals R
Selected
Table 212. Human machine interface selection
Human machine hardware interface
Selection Notes and Rules
Medium size - graphic display, IEC keypad symbols B
Medium size - graphic display, ANSI keypad symbols C
Selected
1MRK 505 346-BEN -
Line differential protection RED670 2.1 IEC
Product version: 2.1
122 ABB
