two master trip, four start, four trip and six alarm signals. The OSWGAPC output is
connected with binary outputs and LEDs via SELGAPC3 and SELGAPC4.
• SELGAPC3 is used to configure OSWGAPC signals to the protection relay's
binary outputs. SELGAPC4 is used to configure OSWGAPC signals to LEDs.
• OSWGAPC1 and OSWGAPC2 are used for the Master trip. The inputs are routed
from the protection function's operate and the circuit breaker failure's re-trip.
• OSWGAPC3 to OSWGAPC6 are used for the start signal. The inputs are start
signals routed from the protection functions.
• OSWGAPC7 to OSWGAPC10 are used for the trip signal. The inputs are
operation signals routed from the protection functions.
• OSWGAPC11 to OSWGAPC16 are used for the alarm signal. The inputs are
alarm signals routed from the protection and monitoring functions.
