Page #181 background imageLoading...
Page #181 background image
Binary inputs of slot X130 are optional for configurations A and B.
Table 34: Binary input terminals X130-1...9
Terminal
Description
X130:1 BI1, +
X130:2 BI1, -
X130:2 BI2, -
X130:3 BI2, +
X130:4 BI3, +
X130:5 BI3, -
X130:5 BI4, -
X130:6 BI4, +
X130:7 BI5, +
X130:8 BI5, -
X130:8 BI6, -
X130:9 BI6, +
Binary inputs of slot X130 are available with configuration C.
Table 35: Binary input terminals X130:1-8 with AIM0006 module
Terminal
Description
X130:1 BI1, +
X130:2 BI1, -
X130:3 BI2, +
X130:4 BI2, -
X130:5 BI3, +
X130:6 BI3, -
X130:7 BI4, +
X130:8 BI4, -
5.2 Outputs
5.2.1 Outputs for tripping and controlling
Output contacts PO1, PO2, PO3 and PO4 are heavy-duty trip contacts capable of
controlling most circuit breakers. On delivery from the factory, the trip signals from
all the protection stages are routed to PO3 and PO4.
1MRS757456 D Section 5
Protection relay's physical connections
REF611 175
Application Manual
