Section 3 REF611 standardized configurations
3.1 Standardized configurations
REF611 is available in three alternative configurations.
To increase the user-friendliness of the configurations and to emphasize the relay's
simplicity of usage, only the application-specific parameters need setting within the
relay's intended area of application.
The standard signal configuration can be altered by local HMI, Web HMI or optional
application functionality of Protection and Control IED Manager PCM600.
Table 9: Standardized configurations
Description Conf.
Non-directional overcurrent and directional earth-fault protection A
Non-directional overcurrent and earth-fault protection B
Directional overcurrent and earth-fault protection C
Table 10: Supported functions
Function
IEC 61850 A B C
Protection
Three-phase non-directional overcurrent protection, low stage PHLPTOC 1 1
Three-phase non-directional overcurrent protection, high stage PHHPTOC 2 2
Three-phase non-directional overcurrent protection, instantaneous stage PHIPTOC 1 1 1
Non-directional earth-fault protection, low stage EFLPTOC
2
1)
Non-directional earth-fault protection, high stage EFHPTOC
1
1)
Non-directional earth-fault protection, instantaneous stage EFIPTOC
1
1)
Three-phase directional overcurrent protection, low stage DPHLPDOC 2
Three-phase directional overcurrent protection, high stage DPHHPDOC 1
Directional earth-fault protection, low stage DEFLPDEF
2
1)2)
2
1)2)
Directional earth-fault protection, high stage DEFHPDEF
1
1)2)
1
1)2)
Transient/intermittent earth-fault protection INTRPTEF 1 1
Non-directional (cross-country) earth fault protection, using calculated Io EFHPTOC
1
3)
1
3)
Negative-sequence overcurrent protection NSPTOC 2 2 2
Phase discontinuity protection PDNSPTOC 1 1 1
Residual overvoltage protection ROVPTOV
3
2)
3
2)
Table continues on next page
1MRS757456 D Section 3
REF611 standardized configurations
REF611 27
Application Manual
