Function IEC 61850 IEC 60617 IEC-ANSI
Logging
Disturbance recorder RDRE1 DR (1) DFR(1)
Fault recorder FLTRFRC1 - FR
Measurement
Three-phase current measurement,
instance 1
CMMXU1 3I 3I
Sequence current measurement CSMSQI1 I1, I2, I0 I1, I2, I0
Residual current measurement,
instance 1
RESCMMXU1 Io In
Three-phase voltage measurement,
instance 1
VMMXU1 3U 3U
Sequence voltage measurement,
instance 1
VSMSQI1 U1, U2, U0 U1, U2, U0
Residual voltage measurement RESVMMXU1 Uo Vn
Frequency measurement, instance 1 FMMXU1 f f
Three-phase power and energy
measurement, instance 1
PEMMXU1 P, E P, E
1) 10 instances
2) 20 instances
3) 6 instances
4) 10 instances
Section 1 1MRS757456 D
Introduction
10 REF611
Application Manual

ABB REF611 Specifications
