CBXCBR1_BLK_CLOSE
CBXCBR1_BLK_OPEN
GOOSERCV_BIN:1
GOOSERCV_BIN:0
OR ISWGAPC9
GOOSE Blcoking
GOOSERCV_BIN:3
GOOSERCV_BIN:2
OR
GOOSE
External Trip
GOOSERCV_BIN:5
GOOSERCV_BIN:4
GOOSERCV_BIN:19
OR ISWGAPC10
GOOSE Block CB
DPHLPDOC1_BLOCK
DPHLPDOC2_BLOCK
DPHHPDOC1_BLOCK
PHIPTOC1_BLOCK
EFHPTOC1_BLOCK
DEFLPDEF1_BLOCK
DEFLPDEF2_BLOCK
DEFHPDEF1_BLOCK
ROVPTOV1_BLOCK
ROVPTOV2_BLOCK
ROVPTOV3_BLOCK
INTRPTEF1_BLOCK
NSPTOC1_BLOCK
NSPTOC2_BLOCK
PDNSPTOC1_BLOCK
T1PTTR1_BLOCK
CBPSOF1_BLOCK
TRPPTRC1_OPERATE
TRPPTRC2_OPERATE
GUID-D433642C-DAC3-4B3F-9076-87393BD13B27 V2 EN
Figure 148: GOOSE overview
ISWGAPC9
ISWGAPC9 is used to configure which protection functions can be blocked by the
received GOOSE signals. ISWGAPC9 inputs are received GOOSE signals from
GOOSERCV_BIN:0 and GOOSERCV_BIN:1. The outputs are connected to block
inputs of the protection functions.
Section 3 1MRS757456 D
REF611 standardized configurations
166 REF611
Application Manual
