<5>:= Step position information M_ST_NA_1
<6>:= Step position information with time tag M_ST_TA_1
<7>:= Bitstring of 32 bit M_BO_NA_1
<8>:= Bitstring of 32 bit with time tag M_BO_TA_1
<9>:= Measured value, normalized value M_ME_NA_1
<10>:= Measured value, normalized value with time tag M_ME_TA_1
<11>:= Measured value, scaled value M_ME_NB_1
<12>:= Measured value, scaled value with time tag M_ME_TB_1
<13>:= Measured value, short floating point value M_ME_NC_1
<14> := Measured value, short floating point value with time tag M_ME_TC_1
<15>:= Integrated totals M_IT_NA_1
<16>:= Integrated totals with time tag M_IT_TA_1
<17>:= Event of protection equipment with time tag M_EP_TA_1
<18>:= Packed start events of protection equipment with time
tag
M_EP_TB_1
<19>:= Packed output circuit information of protection equip-
ment with time tag
M_EP_TC_1
<20>:= Packed single-point information with status change de-
tection
M_SP_NA_1
<21>:= Measured value, normalized value without quality descrip-
tor
M_ME_ND_1
<30>:= Single-point information with time tag CP56Time2a M_SP_TB_1
<31>:= Double-point information with time tag CP56Time2a M_DP_TB_1
<32>:= Step position information with time tag CP56Time2a M_ST_TB_1
<33>:= Bitstring of 32 bit with time tag CP56Time2a M_BO_TB_1
<34>:= Measured value, normalized value with time tag
CP56Time2a
M_ME_TD_1
<35>:= Measured value, scaled value with time tag CP56Time2a M_ME_TE_1
<36>:= Measured value, short floating point value with time tag
CP56Time2a
M_ME_TF_1
Table continues on the next page
