<37>:= Integrated totals with time tag CP56Time2a M_IT_TB_1
<38>:= Event of protection equipment with time tag CP56Time2a M_EP_TD_1
<39>:= Packed start events of protection equipment with time
tag CP56Time2a
M_EP_TE_1
<40>:= Packed output circuit information of protection equip-
ment with time tag CP56Time2a
M_EP_TF_1
Either ASDUs of the set <2>, <4>, <6>, <8>, <10>, <12>, <14>, <16>, <17> or of the set
<30...40> are used.
Process information in control direction
(Station-specific parameter, mark each Type ID with an “X“ if it is only used in the
standard direction, “R“ if only used in the reverse direction, and “B“ if used in both
directions.)
<45>:= Single command C_SC_NA_1
<46>:= Double command C_DC_NA_1
<47>:= Regulating step command C_RC_NA_1
<48>:= Set point command, normalized value C_SE_NA_1
<49>:= Set point command, scaled value C_SE_NB_1
<50>:= Set point command, short floating point value C_SE_NC_1
<51> := Bitstring of 32 bit C_BO_NA_1
<58>:= Single command with CP56Time2a C_SC_TA_1
<57>;= Double command with CP56Time2a C_DC_TA_1
System information in monitor direction
(Station-specific parameter, mark with an “X“ if it is only used in the standard
direction, “R“ if only used in the reverse direction, and “B“ if used in both directions.)
<70> := End of initialization M_EI_NA_1
System information in control direction
(Station-specific parameter, mark each Type ID with an “X“ if it is only used in the
standard direction, “R“ if only used in the reverse direction, and “B“ if used in both
directions.)
<100>:= Interrogation command C_IC_NA_1
<101>:= Counter interrogation command C_CI_NA_1
Table continues on the next page
