Measured value, scaled value M_ME_NB_1, M_ME_TB_1 and M_ME_TE_1
Measured value, short floating point number M_ME_NC_1, M_ME_TC_1 and
M_ME_TF_1
Station interrogation
(Station-specific parameter, mark with an “X“ if the function is only used in the
standard direction, “R“ if only used in the reverse direction, and “B“ if used in both
directions.)
global
group 1 group 7 group 13
group 2 group 8 group 14
group 3 group 9 group 15
group 4 group 10 group 16
group 5 group 11
group 6 group 12
Information object addresses assigned to each group
must be shown in a separate table.
Clock synchronization
(Station-specific parameter, mark with an “X“ if the function is only used in the
standard direction, “R“ if only used in the reverse direction, and “B“ if used in both
directions.)
Clock synchronization
Day of week used
RES1, GEN (time tag substituted/ not substituted) used
SU-bit (summertime) used
Command transmission
(Object-specific parameter, mark with an “X“ if the function is only used in the
standard direction, “R“ if only used in the reverse direction, and “B“ if used in both
directions.)
Direct command transmission
Direct set point command transmission
Select and execute command
Table continues on the next page
IEC 60870-5-104 interoperability 2NGA001859 A
44 REX615
IEC 60870-5-104 Communication Protocol Manual
