5.14.2.3. User mode (see par. 4.5.3)
The dip-switches are to be set as follows: Dip-switch no. 5 = B, Dip-switch no. 11 = ignored.
All contacts (K51/1...K51/8) are associated exclusively with the function selected on the PR331/P unit by the user,
except the K51/5 contact, which indicates the “Communication problems on the local bus (bus KO)” function.
Electric
contact
Event that caused closing of the relay
K51/1
Configured by user on the PR331/P unit
K51/2
Configured by user on the PR331/P unit
K51/3
Configured by user on the PR331/P unit
K51/4
Configured by user on the PR331/P unit
K51/5
Communication problems on the local bus (bus KO)
K51/6
Configured by user on the PR331/P unit
K51/7
Configured by user on the PR331/P unit
K51/8
Configured by user on the PR331/P unit
