ABB SafePlus User Manual

13
6. DIMENSIONS
Height (mm) Standard switchgear Lower version switchgear
Non IAC/IAC AFL without base frame Non IAC/IAC AFL with 290 mm base frame Non IAC/IAC AFL with 450 mm base frame IAC AFLR with 290 mm base frame IAC AFLR with 450 mm base frame Non IAC/IAC AFL without base frame Non IAC/IAC AFL with 290 mm base frame Non IAC/IAC AFL with 450 mm base frame
without low
voltage
compartment or
top entry box
Standard 1336 1626 1786 2002 2002 1100 1390 1550
Top connection without dead ends 1466 1756 1916 2002 2002 1230 1520 1680
Top connection with dead ends 1561 1851 2011 2002 2002 1325 1615 1775
External busbars 1591 1881 2041 2002 2041 1355 1645 1805
Busbar cover 1651 1941 2101 2002 2101 1415 1705 1865
with
top entry box
(124 mm)
Standard 1460 1750 1910 2002 2002 1224 1514 1674
Top connection without dead ends 1466 1756 1916 2002 2002 1230 1520 1680
Top connection with dead ends 1561 1851 2011 2002 2011 1325 1615 1775
External busbars 1591 1881 2041 2002 2041 1355 1645 1805
Busbar cover 1651 1941 2101 2002 2101 1415 1705 1865
with low voltage
compartment
(470 mm) *)
Standard 1806 2096 2256 2096 2256 1570 1860 2020
Top connection without dead ends 1806 2096 2256 2096 2256 1570 1860 2020
Top connection with dead ends 1806 2096 2256 2096 2256 1570 1860 2020
External busbars 1806 2096 2256 2096 2256 1570 1860 2020
Busbar cover 1806 2096 2256 2096 2256 1570 1860 2020
with low voltage
compartment
(700 mm) *)
Standard 2036 2326 2486 2326 2489 1800 2090 2250
Top connection without dead ends 2036 2326 2486 2326 2486 1800 2090 2250
Top connection with dead ends 2036 2326 2486 2326 2486 1800 2090 2250
External busbars 2036 2326 2486 2326 2486 1800 2090 2250
Busbar cover 2036 2326 2486 2326 2486 1800 2090 2250
*) For V-module 12kV/25kA and 24kV/20kA height of low voltage compart-
ment is 570 / 800 mm, so 100 mm has to be added to the total switch-
gear heights in the table

ABB SafePlus Specifications

General

Rated voltage	Up to 24 kV
Rated current	Up to 1250 A
Insulation medium	SF6 gas
Rated Lightning Impulse Withstand Voltage	125 kV
Standards	IEC 62271-200
Dimensions	Varies by configuration
Weight	Varies by configuration
Short-time withstand current	Up to 25 kA
