Section 3 PCM600 Device Configuration Tool
GUID-A1514256-1725-4253-8248-113680BD531E v1
Protection and Control IED Manager PCM600 offers all the necessary functionality to work
throughout all stages of the SAM600 life cycle.
• Planning
• Engineering
• Commissioning
• Operation
• Functional analysis
Specific tool components in PCM600 enable to perform different tasks and functions, and
control the whole substation.
For more information, see PCM600 documentation.
For more information on engineering SAM600 using various tools available
within PCM600, see SAM600 Engineering Manual (1MRK 511 433-UEN).
3.1 Connectivity packages
GUID-7F1E6191-DC72-41F2-B11C-D37D08D6BAA4 v1
A Connectivity package is a software component that consists of executable code and data
which enables IEC 61850 system tools to communicate with a SAM600 system. Connectivity
packages are used to create configuration structures in PCM600.
A connectivity package includes all the data which is used to describe the IED and
communicate with it. For example, it contains a list of the existing parameters, data format
used, as well as units and visibility settings of the parameter.
