Power supply +24 VDC
(redundant power)
X2 2
Power supply - VDC X2 3
Binary input interface X10
Binary input X10 1 Not used
Binary input X10 2 Not used
Binary input X10 3 Not used
Binary input X10 4 Not used
Binary input of common
GND
X10 5 Not used
Shielding GND X10 6 Not used
Shielding GND X10 7 Not used
Internal relay fault X40
Common X40 1
Normally closed X40 2
Normally open X40 3
Optical network
interface
X101/X102
IEC/UCA 61850-9-2LE
process bus/system bus
X101 NA SFP cage for optional
100Base-FX SFP module
IEC/UCA 61850-9-2LE
process bus/system bus
X102 NA SFP cage for optional
100Base-FX SFP module
Copper network
interface
X103/X104
IEC/UCA 61850-9-2LE
process bus/system bus
X103 NA 100Base-TX
IEC/UCA 61850-9-2LE
process bus/system bus
X104 NA 100Base-TX
Configuration interface X105
USB 2.0 configuration
interface (serial
connection)
X105 NA USB-A/USB-A cable
Optical network
interface
X106/X107
IEC/UCA 61850-9-2LE
process bus
X106 NA
IEC/UCA 61850-9-2LE
process bus
X107 NA
1PPS input interface X300
1PPS input X300 NA
1PPS output interface X301-X305
1PPS output X301 NA
1PPS output X302 NA
1PPS output X303 NA
1PPS output X304 NA
1PPS output X305 NA
Table continues on next page
