Table 13: SAM600 LED HMI optical transceiver definition
Pos Description Applies to
SAM600-CT SAM600-
VT
SAM600-TS
LED group D2: Optical transceiver information for X101 and X102
1 NA TX/RX traffic on X102 X X X
2 ON Link indication of port X102 X X X
3 NA TX/RX traffic on X101 X X X
4 ON Link indication of port X101 X X X
LED group D9: Optical transceiver status for X106/X107
1 NA TX/RX traffic on X106 X
2 ON Link indication of port X106 X
3 NA TX/RX traffic on X107 X
4 ON Link indication of port X107 X
Section 7 1MRK 511 434-UEN B
Technical Data
48 SAM600 Process Bus I/O System
Operation Manual
