Zenith ZTGSE/ZTSSE 30-2500A ATS, USER MANUAL
Notice
This installation should be properly operated
and maintained in accordance with the safety
practices of NFPA 70E and/or CSA Z462
Avis
Cette installation doit être correctement
utilisée et entretenue conformément aux
pratiques de sécurité de la norme NFPA 70E
et/ou de la norme CSA Z462.
Before proceeding, refer to the informa-
tion package supplied with the ATS and
read and understand the information on
all accessories provided, including this
complete document.
Before energizing the panel
1. Confirm that installation has been
performed by a qualified person and in
accordance with NFPA 70 (NEC).
—
Initial Energizing
2. Confirm rating label matches the
installed application. Rating label is
located inside the panel enclosure.
3. Confirm that cables are connected
properly and torqued according to the
ATS labeling.
4. Verify that the enclosure ground
connection is properly terminated.
5. If the equipment require to be “Service
Entrance Rated” then follow the instruc-
tion mentioned on page #20.
6. If the equipment require to be “Service
Entrance Rated” then follow the instruc-
tion mentioned on page #20.
7. Confirm that control wiring for engine
start is properly terminated to the en-
gine start contact (located in Fig. 2,
number 8). Additionally, connect all
applicable digital I/O, communications,
and auxiliary contact wiring.
8. Flip slide switch (Fig. 2, number 4)
to AUTO.
9. Ensure that all objects and debris are
removed from enclosure, and enclosure
is closed and latched.
Warning
Shock, Voltage and Arc Flash hazard
Lines of this instructions must be followed as
listed.
Failure to follow these instructions could result
in death or serious injury.
Avertissement
Risque de choc, de tension et d'arc électriqu
Les lignes de ces instructions doivent être
suivies comme indiqué.
Le non-respect de ces instructions peut
entraîner la mort ou des blessures graves.
