Operation Manual / TPL65-A10 / -A30
8 Disassembly and assembly / 8.9 Table of tightening torques
© Copyright 2020 . All rights reserved. HZTL2482_EN Rev.E March 2020
Tightening torques [Nm]
Position Part number TPL65
01 82005 M16x1.5
45
03
1)
72002 M10
04 72027
With washer
M14
95
05 61036
72029
M14
30
06 61044
61059
M14
160
61056 M14
150
06b 61077
If provided
M14
20
07 42059
42064
M12
45
10 61037 M14
75
11 61090 M14
10
14 86505 M18x1.5
150
1)
Screw in the screw (72002) as far as it will go and then un-
screw it by ¼ turn. The screw must be loose and the diffuser
must be movable.
