Operation Manual / TPL65-A10 / -A30
2 Safety / 2.5 Warning plates on the turbocharger
© Copyright 2020 . All rights reserved. HZTL2482_EN Rev.E March 2020
2.5 Warning plates on the turbocharger
Warning plates that must be observed are attached to the turbocharger.
The warning plates must always be present in the intended locations
and must be legible.
Fig.1: Warning plate
Part number Size [mm] Product
81080 105 x 74 TPL
When uninsulated turbochargers are delivered to the engine builder, the
warning plates must be subsequently attached to the insulation. This is
the responsibility of the engine builder.
