Operation Manual / TPL67-C.. - TPL71-C..
© Copyright 2016 ABB. All rights reserved.
April 2016 HZTL2488_EN Revision C
3 Hexagon-head screw 61059
1 Gasket 77005
1 O-ring (speed sensor) 86506
Spare parts set (97078) for turbine cleaning system (if provided)
Improper assembly of the cleaning pipe and the nozzles can lead to
leaks and failure of the turbine cleaning system.
Work on turbine cleaning system should be carried out only by an
ABB Turbocharging service station.
2 Hexagon-head screw 52205
2 Hexagon-head screw 52257
2 Hexagon-head screw 52205
2 Hexagon-head screw 52257
