View of turbocharger with part numbers
12.2
Page 123
© Copyright 2016 ABB. All rights reserved.
April 2016 HZTL2488_EN Revision C
Part number
Description
42012 (in customer spare part set) O-ring
51001
Gas inlet casing
51012 Segment
56001
Nozzle ring
61001 Gas outlet casing
61037 (in customer spare part set)
Hexagon nut
61044 Hexagon-head screw
61050 (if provided)
Gasket
61056 (in customer spare part set) Hexagon-head screw
61057 (in customer spare part set)
Verbus Ripp® Washer
61058 (in customer spare part set) Verbus Ripp® Washer
61059 (in customer spare part set)
Hexagon-head screw
63000 Turbine diffuser
68001
Foot at compressor end
68002 Foot at turbine end
68003
Slide plate
68006 Cup spring
68007
Bush
72000 Compressor casing
77000
Wall insert
77005 (in customer spare part set) O-ring
79000
Diffuser
81000 Filter silencer
82000
Radial air suction branch
