Operation Manual / TPS48-D/E.. - TPS61-D/E..
Operation
4
Noise emissions
4.1
Page 44
© Copyright 2016 ABB. All rights reserved.
September 2016 HZTL2410_EN Revision E
Suggestion for noise insulation of the bellows
01 Compressor casing 04 Insulation pads
02
Bellows
05
Insulation mat (at least 15 mm)
03 Charge air duct / scavenging
air line
06 Sheet metal cover
