TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
164
Register
Address
3 Winding
Item Description
Bit 4 = Reserved
Bit 5 = Reserved
Bit 6 = Reserved
Bit 7 = Reserved
Bit 8 = Reserved
Bit 9 = Reserved
Bit 10 = Reserved
Bit 11 = Reserved
Bit 12 = Reserved
Bit 13 = Reserved
Bit 14 = Reserved
Bit 15 = Reserved (msb)
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
42694 READ DATA – Trigger Flag Word 4
Bit 0 = 50N-1 (lsb)
Bit 1 = 50N-2
Bit 2 = 50N-3
Bit 3 = 51N
Bit 4 = 50P-1
Bit 5 = 50P-2
Bit 6 = 50P-3
Bit 7 = 51P
Bit 8 = 67P
Bit 9 = 67N
Bit10 = 46
Bit 11 = 27
Bit 12 = 59
Bit 13 = 79V
Bit 14 = 81S-1
Bit 15 = 81R –1 (msb)
Unsigned Integer (16 Bits)
Neutral. Instantaneous Overcurrent Trip
Neutral. Instantaneous Overcurrent Trip
Neutral. Instantaneous Overcurrent Trip
Neutral Time Overcurrent Trip
Phase Instantaneous Overcurrent Trip
Phase Instantaneous Overcurrent Trip
Phase Instantaneous Overcurrent Trip Phase
Time Overcurrent Trip
Direct Overcurrent Trip Positive Sequence
Direct Overcurrent Trip Negative Sequence
Negative Sequence Overcurrent Trip
Undervoltage Trip
Overcurrent Trip
Recloser Lockout
Frequency Shed (First Stage)
Frequency Restore (First Stage)
DATE/TIMESTAMPS OF TRIGGER POINT
42695 Year Unsigned Integer 16 Bits
0-99
42696 Month Unsigned Integer 16 Bits
1- 12
42697 Day Unsigned Integer 16 bits
1-31
42698 Hour Unsigned Integer 16 Bits
0-23
42699 Minute Unsigned Integer 16 Bits
0-59
42700 Second Unsigned Integer 16 Bits
0-59
42701 Hundredths of Seconds Unsigned Integer 16 Bits
0 – 99
42702 Quarter Cycle Trigger Point Unsigned Integer 16 Bits
Number of 1/4 Cycle of Trigger Point
0-255 ( Dependent on 6X Register Config)
42703 Total Number of Channels Unsigned Integer 16 Bits
Default as 7
42704 Total Analog Data Channels Unsigned Integer 16 Bits
FIXED at 7
42705 Total Digital Data Channels Unsigned Integer 16 Bits
0 <=Range <= 64
LINE FREQUENCY OF WAVEFORM
42706 Line Frequency Unsigned Integer 16 Bits
