TPU2000/2000R Modbus/Modbus Plus Automation Guide
165
Register
Address
3 Winding
Item Description
50 or 60 Hz
SAMPLE RATE INFORMATION
42707 Reserved Reserved
42708 Reserved Reserved
42709 Reserved Reserved
CHANNEL NAMES, UNITS, AND CONVERSIONS
42710 CHANNEL 1 – Channel Number Unsigned Integer 16 Bits
See Note 1
42711 CHANNEL 1 – Channel Name 2 Digits ASCII
42712 CHANNEL 1 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42713 CHANNEL 1 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42714 CHANNEL 1 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42715 CHANNEL 1 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42716 CHANNEL 1 – Scale Factor Denominator) Unsigned 32 Bit High Order Word ( MSW)
42717 CHANNEL 1 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42718 CHANNEL 2 – Channel Number Unsigned Integer 16 Bits
See Note 1
42719 CHANNEL 2 – Channel Name 2 Digits ASCII
42720 CHANNEL 2 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42721 CHANNEL 2 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42722 CHANNEL 2 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42723 CHANNEL 2 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42724 CHANNEL 2 – Scale Factor Denominator Unsigned 32 Bit High Order Word (MSW)
42725 CHANNEL 2 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42726 CHANNEL 3 – Channel Number Unsigned Integer 16 Bits
See Note 1
42727 CHANNEL 3 – Channel Name 2 Digits ASCII
42728 CHANNEL 3 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42729 CHANNEL 3 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42730 CHANNEL 3 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42731 CHANNEL 3 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42732 CHANNEL 3 – Scale Factor Denominator Unsigned 32 Bit High Order Word ( MSW)
42733 CHANNEL 3 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42734 CHANNEL 4 – Channel Number Unsigned Integer 16 Bits
See Note 1
42735 CHANNEL 4 – Channel Name 2 Digits ASCII
42736 CHANNEL 4 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42737 CHANNEL 4 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42738 CHANNEL 4 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42739 CHANNEL 4 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42740 CHANNEL 4 – Scale Factor Denominator Unsigned 32 Bit High Order Word (MSW)
42741 CHANNEL 4 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
