ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
166
Register
Address
3 Winding
Item Description
42742 CHANNEL 5 – Channel Number Unsigned Integer 16 Bits
See Note 1
42743 CHANNEL 5 – Channel Name 2 Digits ASCII
42744 CHANNEL 5 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42745 CHANNEL 5 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42746 CHANNEL 5 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42747 CHANNEL 5 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42748 CHANNEL 5 – Scale Factor Denominator Unsigned 32 Bit High Order Word (MSW)
42749 CHANNEL 5 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42750 CHANNEL 6 – Channel Number Unsigned Integer 16 Bits
See Note 1
42751 CHANNEL 6 – Channel Name 2 Digits ASCII
42752 CHANNEL 6 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42753 CHANNEL 6 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42754 CHANNEL 6 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42755 CHANNEL 6 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42756 CHANNEL 6 – Scale Factor Denominator Unsigned 32 Bit High Order Word (MSW)
42757 CHANNEL 6 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42758 CHANNEL 7 – Channel Number Unsigned Integer 16 Bits
See Note 1
42759 CHANNEL 7 – Channel Name 2 Digits ASCII
42760 CHANNEL 7 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42761 CHANNEL 7 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42762 CHANNEL 7 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42763 CHANNEL 7 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42764 CHANNEL 7 – Scale Factor Denominator Unsigned 32 Bit High Order Word ( MSW)
42765 CHANNEL 7 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42766 CHANNEL 7 – Channel Number Unsigned Integer 16 Bits
See Note 1
42767 CHANNEL 8 – Channel Name 2 Digits ASCII
42768 CHANNEL 8 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42769 CHANNEL 8 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42770 CHANNEL 8 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42771 CHANNEL 8 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42772 CHANNEL 8 – Scale Factor Denominator Unsigned 32 Bit High Order Word (MSW)
42773 CHANNEL 8 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42774 CHANNEL 9 – Channel Number Unsigned Integer 16 Bits
See Note 1
42775 CHANNEL 9 – Channel Name 2 Digits ASCII
42776 CHANNEL 9 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
