ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus Automation Guide
167
Register
Address
3 Winding
Item Description
42777 CHANNEL 9 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42778 CHANNEL 9 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42779 CHANNEL 9 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42780 CHANNEL 9 – Scale Factor Denominator Unsigned 32 Bit High Order Word (MSW)
42781 CHANNEL 9 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42782 CHANNEL 10 – Channel Number Unsigned Integer 16 Bits
See Note 1
42783 CHANNEL 10 – Channel Name 2 Digits ASCII
42784 CHANNEL 10 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42785 CHANNEL 10 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42786 CHANNEL 10 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42787 CHANNEL 10 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42788 CHANNEL 10 – Scale Factor Denominator Unsigned 32 Bit High Order Word (MSW)
42789 CHANNEL 10 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42790 CHANNEL 11 – Channel Number Unsigned Integer 16 Bits
See Note 1
42791 CHANNEL 11 – Channel Name 2 Digits ASCII
42792 CHANNEL 11 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42793 CHANNEL 11 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42794 CHANNEL 11 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42795 CHANNEL 11 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42796 CHANNEL 11 – Scale Factor Denominator Unsigned 32 Bit High Order Word (MSW)
42797 CHANNEL 11 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42798 CHANNEL 12 – Channel Number Unsigned Integer 16 Bits
See Note 1
42799 CHANNEL 12 – Channel Name 2 Digits ASCII
42800 CHANNEL 12 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42801 CHANNEL 12 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42802 CHANNEL 12 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42803 CHANNEL 12 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42804 CHANNEL 12 – Scale Factor Denominator Unsigned 32 Bit High Order Word (MSW)
42805 CHANNEL 12 – Scale Factor Denominator Unsigned 32 Bit Low Order Word (MSW)
42806 CHANNEL 7 – Channel Number Unsigned Integer 16 Bits
See Note 1
42807 CHANNEL 7 – Channel Name 2 Digits ASCII
42808 CHANNEL 7 – Channel Phase
Identification
Unsigned Integer 16 Bits
See Note 1
42809 CHANNEL 7 – Channel Units Unsigned Integer 16 Bits
1 = Amps
2 = Volts
42810 CHANNEL 7 – Scale Factor Numerator Unsigned 32 Bit High Order Word (MSW)
42811 CHANNEL 7 – Scale Factor Numerator Unsigned 32 Bit Low Order Word (LSW)
42812 CHANNEL 7 – Scale Factor Denominator Unsigned 32 Bit High Order Word (MSW)
