TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
268
Offset 114: Unsigned Word 1 Load Current Zero Sequence Angle Winding 2
Offset 116: Unsigned Word 1 Load Current Positive Sequence Angle Winding 2
Offset 118: Unsigned Word 1 Load Current Negative Sequence Angle Winding 2
Offset 120: Unsigned Word 1 Load Current Zero Sequence Angle Winding 3
Offset 122: Unsigned Word 1 Load Current Positive Sequence Angle Winding 3
Offset 124: Unsigned Word 1 Load Current Negative Sequence Angle Winding 3
BLK 3:
RMS VOLTAGE/ANGULAR/REAL and REACTIVE POWER/ENERGY VALUES BLOCK
Block Offset
Data Size Scale Description
Offset 0: Unsigned Long 1 Voltage VA
Offset 4: Unsigned Long 1 Voltage VB
Offset 8: Unsigned Long 1 Voltage VC
Offset 12: Unsigned Word 1 Voltage VA Angle
Offset 14: Unsigned Word 1 Voltage VB Angle
Offset 16: Unsigned Word 1 Voltage VC Angle
Offset 18: Unsigned Long 1 Voltage Positive Sequence
Offset 22: Unsigned Long 1 Voltage Negative Sequence
Offset 26: Unsigned Word 1 Voltage Positive Sequence Angle
Offset 28: Unsigned Word 1 Voltage Negative Sequence Angle
Offset 30: Signed Long 1 kWatts A
Offset 34: Signed Long 1 kWatts B
Offset 38: Signed Long 1 kWatts C
Offset 42: Signed Long 1 kVars A
Offset 46: Signed Long 1 kVars B
Offset 50: Signed Long 1 kVars C
Offset 54: Signed Long 1 kWatt Hours A
Offset 58: Signed Long 1 kWatt Hours B
Offset 62: Signed Long 1 kWatt Hours C
Offset 66: Signed Long 1 kVar Hours A
Offset 70: Signed Long 1 kVar Hours B
Offset 74: Signed Long 1 kVar Hours C
Offset 78 Signed Long 1 3 Phase kWatts
Offset 82 Signed Long 1 3 Phase kVars
Offset 86 Signed Long 1 3 Phase kWatt Hours
Offset 90 Signed Long 1 3 Phase kVar Hours
Offset 94 Signed Long 1 3 Phase kVA
Offset 98 Unsigned Short 100 System Frequency
Offset 100 Unsigned Short Power Factor
Bit 15-9: Not used
Bit 8: 0=Positive, 1=Negative
Bit 7: 0=Leading, 1=Lagging
Bit 6-0: Power Factor Value (x100)
BLK 4:
RMS DEMAND CURRENT/REAL and REACTIVE POWER VALUES BLOCK
Block Offset
Data Size Scale Description
Offset 0: Signed Long 1 Demand Current-A
Offset 4: Signed Long 1 Demand Current-B
Offset 8: Signed Long 1 Demand Current-C
Offset 12: Signed Long 1 Demand Current-N
Offset 16: Signed Long 1 Demand kWatts-A
Offset 20: Signed Long 1 Demand kWatts-B
Offset 24: Signed Long 1 Demand kWatts-C
Offset 28: Signed Long 1 Demand kVars-A
Offset 32: Signed Long 1 Demand kVars-B
Offset 36: Signed Long 1 Demand kVars-C
Offset 40: Signed Long 1 3 Phase Demand Watts
Offset 44: Signed Long 1 3 Phase Demand Vars
