TPU2000/2000R Modbus/Modbus Plus Automation Guide
269
BLK 5:
RMS PEAK DEMAND CURRENT/REAL and REACTIVE POWER VALUES and TIME STAMPS
BLOCK
Block Offset
Data Size Scale Description
Offset 0: Signed Long 1 Peak Demand Current-A
Offset 4: Unsigned Byte Peak Demand Current-A Year
Offset 5: Unsigned Byte Peak Demand Current-A Month
Offset 6: Unsigned Byte Peak Demand Current-A Day
Offset 7: Unsigned Byte Peak Demand Current-A Hour
Offset 8: Unsigned Byte Peak Demand Current-A Minute
Offset 9: Unsigned Byte Spare
Offset10: Signed Long 1 Peak Demand Current-B
Offset14: Unsigned Byte Peak Demand Current-B Year
Offset15: Unsigned Byte Peak Demand Current-B Month
Offset16: Unsigned Byte Peak Demand Current-B Day
Offset17: Unsigned Byte Peak Demand Current-B Hour
Offset18: Unsigned Byte Peak Demand Current-B Minute
Offset19: Unsigned Byte Spare
Offset 20: Signed Long 1 Peak Demand Current-C
Offset 24: Unsigned Byte Peak Demand Current-C Year
Offset 25: Unsigned Byte Peak Demand Current-C Month
Offset 26: Unsigned Byte Peak Demand Current-C Day
Offset 27: Unsigned Byte Peak Demand Current-C Hour
Offset 28: Unsigned Byte Peak Demand Current-C Minute
Offset 29: Unsigned Byte Spare
Offset 30: Signed Long 1 Peak Demand Current-N
Offset 34: Unsigned Byte Peak Demand Current-N Year
Offset 35: Unsigned Byte Peak Demand Current-N Month
Offset 36: Unsigned Byte Peak Demand Current-N Day
Offset 37: Unsigned Byte Peak Demand Current-N Hour
Offset 38: Unsigned Byte Peak Demand Current-N Minute
Offset 39: Unsigned Byte Spare
Offset 40: Signed Long 1 Peak Demand KWatts-A
Offset 44: Unsigned Byte Peak Demand KWatts-A Year
Offset 45: Unsigned Byte Peak Demand KWatts-A Month
Offset 46: Unsigned Byte Peak Demand KWatts-A Day
Offset 47: Unsigned Byte Peak Demand KWatts-A Hour
Offset 48: Unsigned Byte Peak Demand KWatts-A Minute
Offset 49: Unsigned Byte Spare
Offset 50: Signed Long 1 Peak Demand KWatts-B
Offset 54: Unsigned Byte Peak Demand KWatts-B Year
Offset 55: Unsigned Byte Peak Demand KWatts-B Month
Offset 56: Unsigned Byte Peak Demand KWatts-B Day
Offset 57: Unsigned Byte Peak Demand KWatts-B Hour
Offset 58: Unsigned Byte Peak Demand KWatts-B Minute
Offset 59: Unsigned Byte Spare
Offset 60: Signed Long 1 Peak Demand KWatts-C
Offset 64: Unsigned Byte Peak Demand KWatts-C Year
Offset 65: Unsigned Byte Peak Demand KWatts-C Month
Offset 66: Unsigned Byte Peak Demand KWatts-C Day
Offset 67: Unsigned Byte Peak Demand KWatts-C Hour
Offset 68: Unsigned Byte Peak Demand KWatts-C Minute
Offset 69: Unsigned Byte Spare
Offset 70: Signed Long 1 Peak Demand KVars-A
Offset 74: Unsigned Byte Peak Demand KVars-A Year
Offset 75: Unsigned Byte Peak Demand KVars-A Month
Offset 76: Unsigned Byte Peak Demand KVars-A Day
Offset 77: Unsigned Byte Peak Demand KVars-A Hour
