TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
52
Register
Address
Item Description
00590: 46-2D MOMENTARY Winding 1 Negative Sequence Time Overcurrent Function
Disabled Alarm (Momentary)
00591: PATA STATUS Phase A Target Alarm Energized (Status)
00592: PATA MOMENTARY Phase A Target Alarm Energized (Momentary)
00593: PBTA STATUS Phase B Target Alarm Energized (Status)
00594: PBTA MOMENTARY Phase B Target Alarm Energized (Momentary)
00595: PCTA STATUS Phase C Target Alarm Energized (Status)
00596: PCTA MOMENTARY Phase C Target Alarm Energized (Momentary)
00597: PUA STATUS Pick Up Alarm Energized (Status)
00598: PUA MOMENTARY Pick Up Alarm Energized (Momentary)
00599: 63 STATUS Sudden Pressure Input Alarm Energized (Status)
00600: 63 MOMENTARY Sudden Pressure Input Alarm Energized (Momentary)
00601: THRUFA STATUS Through Fault Alarm Energized (Status)
00602: THRUFA MOMENTARY Through Fault Alarm Energized (Momentary)
00603: TFCA STATUS Through Fault Counter Alarm Energized (Status)
00604: TFCA MOMENTARY Through Fault Counter Alarm Energized (Momentary)
00605: TFKA-2 STATUS Through Fault KiloAmp Symmetrical Alarm Winding 2
Energized. (Status)
00606: TFKA-2 MOMENTARY Through Fault KiloAmp Symmetrical Alarm Winding 2
Energized. (Momentary)
00607: TFSCA STATUS Through Fault Summation Cycle Alarm Energized (Status)
00608: TFSCA MOMENTARY Through Fault Summation Cycle Alarm Energized
(Momentary)
00609: DTC STATUS Differential Trip Current Alarm Energized (Status)
00610: DTC MOMENTARY Differential Trip Current Alarm Energized (Momentary)
00611: OCTC STATUS Overcurrent Trip Counter Alarm Energized (Status)
00612: OCTC MOMENTARY Overcurrent Trip Counter Alarm Energized (Momentary)
00613: PDA STATUS Phase Demand Current Alarm Energized (Status)
00614: PDA MOMENTARY Phase Demand Current Alarm Energized (Momentary)
00615: NDA STATUS Neutral Demand Current Alarm Energized (Status)
00616: NDA MOMENTARY Neutral Demand Current Alarm Energized (Momentary)
00617: PRIM STATUS Primary Settings Alarm Energized (Status)
00618: PRIM MOMENTARY Primary Settings Alarm Energized (Momentary)
00619: ALT1 STATUS Alternate 1 Settings Enabled (Status)
00620: ALT1 MOMENTARY Alternate 1 Settings Enabled (Momentary)
00621: ALT2 STATUS Alternate 2 Settings Enabled (Status)
00622: ALT2 MOMENTARY Alternate 2 Settings Enabled (Momentary)
00623: STCA STATUS Settings Table Changed Alarm Energized (Status)
00624: STCA MOMENTARY Settings Table Changed Alarm Energized (Momentary)
(L)
00625: 87T STATUS Harmonic Restrained % Differential Trip Alarm Energized
(Status)
(L)
00626: 87T MOMENTARY Harmonic Restrained % Differential Trip Alarm Energized
(Momentary)
(L)
00627: 87H STATUS Unrestrained High Set Instantaneous Differential Trip Alarm
Energized (Status)
(L)
00628: 87H MOMENTARY Unrestrained High Set Instantaneous Differential Trip Alarm
Energized (Momentary)
(L)
00629: 2HROA STATUS 2
nd
Harmonic Restraint Alarm Energized (Status)
(L)
00630: 2HROA MOMENTARY 2
nd
Harmonic Restraint Alarm Energized (Momentary)
(L)
00631: 5HROA STATUS 5
th
Harmonic Restraint Alarm Energized (Status)
(L)
00632: 5HROA MOMENTARY 5
th
Harmonic Restraint Alarm Energized (Momentary)
(L)
00633: AHROA STATUS All Harmonics Restraint Alarm (2
nd
through11th Harmonic)
Energized (Status)
(L)
00634: AHROA MOMENTARY
A
ll Harmonics Restraint Alarm
(
2
nd
throu
g
h11th Harmonic
)
