ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus Automation Guide
53
Register
Address
Item Description
Energized (Momentary)
(L)
00635: 51P-1 STATUS Winding 1 Phase Time Overcurrent Alarm Energized (Status)
(L)
00636: 51P-1 MOMENTARY Winding 1 Phase Time Overcurrent Alarm Energized
(Momentary)
(L)
00637: 51P-2 STATUS Winding 2 Phase Time Overcurrent Alarm Energized (Status)
(L)
00638: 51P-2 MOMENTARY Winding 2 Phase Time Overcurrent Alarm Energized
(Momentary)
(L)
00639: 50P-1 STATUS 1
st
Winding 1 Phase Instantaneous Overcurrent Trip Alarm
Energized (Status)
(L)
00640: 50P-1 MOMENTARY 1
st
Winding 1 Phase Instantaneous Overcurrent Trip Alarm
Energized (Momentary)
(L)
00641: 150P-1 STATUS 2
nd
Winding 1 Phase Instantaneous Overcurrent Trip Alarm
Energized (Status)
(L)
00642: 150P-1 STATUS 2
nd
Winding 1 Phase Instantaneous Overcurrent Trip Alarm
Energized (Status)
(L)
00643: 50P-2 1
st
Winding 2 Phase Instantaneous Overcurrent Trip Alarm
Energized
(L)
00644: 50P-2 1
st
Winding 2 Phase Instantaneous Overcurrent Trip Alarm
Energized
(L)
00645: 150P-2 2
nd
Winding 2 Phase Instantaneous Overcurrent Trip Alarm
Energized
(L)
00646: 150P-2 2
nd
Winding 2 Phase Instantaneous Overcurrent Trip Alarm
Energized
(L)
00647: 51N-1 Winding 1 Neutral Time Overcurrent Trip Alarm Energized
(L)
00648: 51N-1 Winding 1 Neutral Time Overcurrent Trip Alarm Energized
(L)
00649: 51N-2 Winding 1 Neutral Time Overcurrent Trip Alarm Energized
(L)
00650: 51N-2 Winding 1 Neutral Time Overcurrent Trip Alarm Energized
(L)
00651: 50N-1 1
st
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm
Energized
(L)
00652: 50N-1 1
st
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm
Energized
(L)
00653: 150N-1 2
nd
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm
Energized
(L)
00654: 150N-1 2
nd
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm
Energized
(L)
00655: 50N-2 1
st
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm
Energized
(L)
00656: 50N-2 1
st
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm
Energized
(L)
00657: 150N-2 2
nd
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm
Energized
(L)
00658: 150N-2 2
nd
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm
Energized
(L)
00659: 46-1 Winding 1 Negative Sequence Time Overcurrent Trip Alarm
Energized
(L)
00660: 46-1 Winding 1 Negative Sequence Time Overcurrent Trip Alarm
Energized
(L)
00661: 46-2 Winding 1 Negative Sequence Time Overcurrent Trip Alarm
Energized
(L)
00662: 46-2 Winding 1 Negative Sequence Time Overcurrent Trip Alarm
Energized
(L)
00663: 63 Sudden Pressure Seal In Alarm Energized
(L)
00664: 63 Sudden Pressure Seal In Alarm Energized
00665: ULO 1 User Logical Output 1
00666: ULO 1 User Logical Output 1
