ABB UniGear ZS3.2

22 UniGear ZS3.2 INSTRUCTION MANUAL
—
5/1 Guideline
structural data for
foundation frame
on concrete floor
(for information
only)
—
5/1
1500
200220430
1685
50 50
50
(360)(360)
Only for transformer
panel
(1600) (1600)1600 1200 1200
6006001000
1340
300
6033
300300
3333 6060
M12(4X)
35
50 300 105 480
(130)
1000
665
30
260
30
940 940
(280)(280) (280)(280)
B
A
C1
C1 C1
C2 C2
25652000
E
A Operator aisle
B Inspection aisle
C1 Opening for power cables
C2 Opening for control cables(instead of individual openings,
continuous openings or drilled holes are possible)
E Points for fixing the switchgear panel on the floor frame
