ABB XRC G5 - Figure 8-19: Enable Bluetooth

To Next Page

To Previous Page

72 | XSE RI ES G5 | 210602 6MNAA

Figure 8-19: Enable Bluetooth

Select the Communication Setup tab. The Bluetooth interface is unused in the port list.

Figure 8-20: Communication Setup for Bluetooth

Select Bluetooth (Unused).

Select Add New Device/Application. See the figure below.
