2-18 Chapter2
SL6
Serial Port COM1 Connector
This motherboard provides one COM port.
You can connect an external modem, mouse
or other devices that support this
communication protocol to this connector.
You can decide which external device you
want to connect to COM1. The COM port
can only have one device connected at a
time.
Parallel Port Connector
This parallel port is also called an “LPT”
port because it usually connects to the
printer. You can connect other devices that
support this communication protocol, like
an EPP/ECP
scanner, etc.
