3-38 Chapter3
SL6
Suspend Type:
Two options are available: Stop Grant and PwrOn Suspend. The default setting is Stop
Grant.
Modem Use IRQ:
You can specify the IRQ for modem use. Eight options are available: N/A ) 3 ) 4 ) 5 )
7 ) 9 ) 10 ) 11. The default setting is N/A.
Suspend Mode/HDD Power Down:
These two items will be enable to change setting when item Power Management is set to
User Define, theses two item will also changes as table 3-6-3 below.
Table 3-6-3: Power Management Settings
Power Management SettingsItems
User Define Min Saving Max Saving
Suspend Mode
Disabled ) 1 Min ) 2 Min ) 4 Min
) 8 Min ) 12 Min ) 20 Min ) 30
Min ) 40 Min ) 1 Hour. The default
setting is Disabled.
1 Hour 1 Min
HDD Power Down
Disabled ) 1 Min ) 2 Min ) 3 Min
) 4 Min ) 5 Min ) 6 Min ) 7 Min
) 8 Min ) 9 Hour ) 10 Min ) 11
Min ) 12 Min ) 13 Min ) 14 Min )
15 Min. The default setting is Disabled.
15 Min 1 Min
Soft-Off by PWR-BTTN:
Two options are available: Instant-Off and Delay 4 Sec.. The default setting is Instant-Off.
Pressing the power button for more than four seconds forces the system to enter the Soft-Off
state when the system has "hung".
Wake-Up by PCI card:
Two options are available: Enabled and Disabled. Default setting is Disabled. This item can
let you wake-up your computer by PCI devices. For instance, if you had installed a PCI LAN
card with Wake-Up on LAN capability, then you could wake-up your computer from
