INSTALLATION AND POWER SUPPLY CONNECTION
11
3. Loosen the lower screws in the terminal blocks, insert the supply cable wires into
their respective terminals and tighten with a torque of 2.5 to 3 Nm. The wiring se-
quence is shown in the following table.
The supply cable for the 1 phase EVSE 813 model variant is connected as follows:
DESIGNATION WIRE COLORS CONNECTION CODING
Current-carrying conductor Brown L1
Neutral Blue N
Protective earth Green-Yellow PE
The supply cable for the 3 phase EVSE 803 model variant is connected as follows:
DESIGNATION WIRE COLORS CONNECTION CODING
Current-carrying conductor
phase 1
Brown L1
Current-carrying conductor
phase 2
Black L2
Current-carrying conductor
phase 3
Gray L3
Neutral Blue N
Protective earth Green-Yellow PE
DANGER!
The above color-coding is not internationally standardized: Should the in-
dividual wires in the power supply cable be color-coded differently, please
immediately contact a qualified electrical contractor! Have the power sup-
ply checked and replaced if necessary.
After successful connection to the power supply by a qualified electric contractor,
please take the following steps to complete installation:
1. Replace the upper part of the housing onto the rear part of the housing.
2. Fix the upper housing part to the rear part using the appropriate screws.
3. Switch the integrated RCCB of the wallbox back on.
4. Lock the cover shield of the EVSE 803/813 using the key supplied and store the
key in a safe place.
5. In your domestic power distribution box, switch the upstream MCB for EVSE
803/813 back on.
This step concludes the installation of the EVSE 803/813.
