TAKING INTO OPERATION AND CHARGING PROCEDURE
13
Normal operation
The fixed charging cable leaves the wallbox on the left lower side of the housing. A
matching compartment for the charging connector is provided on the right side of the
housing: A pin inside the compartment, onto which the connector is hooked, serves
to secure it in place.
DANGER!
Except during charging procedures, the charging connector must always
be properly stored and thereby secured in its compartment: Never leave
the connector lying out in the open or plugged into the vehicle after charg-
ing is complete.
You must under no circumstances use excessive force when removing the charging
connector from its compartment or replacing it: If the pin inside the compartment is
damaged or breaks off, the charging connector can no longer be stored properly. In
this case you must under no circumstances continue to operate the wallbox! Please
contact your local distributor from whom you have purchased the wallbox.
The fixed charging cable of the EVSE 803/813 is ca. 7 meters in length and thus en-
ables a flexible connection with the vehicle. Unless charging, you should always roll
the cable up into a compact shape and store it in a way that prevents it from being
damaged by external mechanical forces. Although the cable and connector are de-
signed to withstand high mechanical stresses, you should not drive your vehicle over
the cable and/or the connector. Also ensure that the cable is not kinked at the housing
outlet and that there is no excessive strain on the cable and/or the housing.
DANGER!
If the cable, the charging connector and/or the housing have suffered mechan-
ical damage or show visible deformities, you must under no circumstanc-
es continue to operate the wallbox.
Please contact your local distributor from whom you have purchased the
wallbox.
Charging procedure
The EVSE 803/813 is engineered for the fastest possible charging of your vehicle ac-
cording to IEC 61851-1, Mode 3. The actual charging time depends on the battery fitted
to your vehicle as well as on the energy currently remaining in the vehicle. For these
reasons it is not possible to make a reliable prediction of the charging time: You will dis-
cover its actual value in practice and derive your personal charging routine accordingly.
Please follow the following steps to charge your vehicle:
1. Park your vehicle so that the charging socket can be easily reached with the charg-
ing connector: The charging cable must not be under any strain during the charging
procedure!
