Page #24 background imageLoading...
Page #24 background image
APPENDIX
20
Appendix
Technical specifications
MODEL VARIANT EVSE 803 EVSE 813
Compliance IEC 61851-1/22
Rated voltage 230/400 V 50 Hz 230 V 50 Hz
Rated current
16 A (MCB required
onsite)
32 A (MCB required
onsite)
Max. output 11 kW 7.2 kW
Charging cable Type 2, length ca. 7 m
Circuit-protection devices
Type A 30 mA RCCB, and DC-RCM I
Δn d.c. electronic
DC fault current detector
6 mA
Energy meter -
Control / Customization internal RS485 interface
Terminal block up to 6 mm
2
up to 6 mm
2
Operating temperature -30°C to 50°C
Storage temperature -30°C to 85°C
Relative humidity 5 to 95% (no condensation)
Class of protection I
Degree of protection
(housing)
IP54
Overvoltage category III
Dimensions 482 x 226 x 143 mm (H x W x D)
Weight per unit ca. 5.6 kg
Standards & guidelines
Your eMH1 EVSE 803/813 Wallbox complies with the following standards and classes
of protection:
General standards
STANDARD DESCRIPTION
2004/108/EC EMC Guideline
2002/95/EC RoHS Guideline
2002/96/EC WEEE Guideline
