APPENDIX
24
• The recommended shaft diameter for the fixings is 5 mm, with the drill hole diam-
eter to be selected accordingly.
• All three screws and respective drill holes indicated on the drilling template
must
under all circumstances be used to fix eMH1 Wallboxes.
• Ensure that the selected installation site is suitable for mounting the wallbox with
respect to substrate, power supply/cabling path, distance to the vehicle and environ-
mental conditions.
• Strictly observe all instructions regarding mounting position and height. You will find
the necessary information in section “Prerequisites for the mounting site and instal-
lation” on page 7.
• Check the measurements on the drilling template BEFORE you mark and drill the
holes using the template.
WARNING!
Consider leaving the final installation to a qualified and authorized elec-
trical contractor: Should malfunctions occur that can be shown to have
resulted from improper mounting and installation, all guarantee and
warranty provisions will become void. Proof of proper installation (e.g.
by submitting the relevant invoices) must be furnished on request before
guarantee and warranty provisions come into effect.
Warranty and guarantee provisions
ABL provides the legally prescribed guarantee period as well as a warranty of the
same duration for the country in which the product was purchased. Should the product
be operated in another country, the legal provisions of the country of purchase apply
nevertheless: Under no circumstances are guarantees or the warranty transferable.
Should modifications of any kind have been made to the product that have not been
explicitly authorized by ABL or described in the guidelines for authorized service part-
ners, the manufacturer’s warranty obligations become void with immediate effect.
On-site repairs are generally excluded by the manufacturer. In case of disregard of this
provision, all guarantee and warranty provisions become void with immediate effect.
WARNING!
Should problems occur when operating your product, please contact
your local distributor immediately and clarify whether the malfunc-
tion is covered by guarantee or warranty provisions.
Do not under any circumstances make alterations or repairs to your prod-
uct yourself!
After delivery, ABL guarantees the proper operation of the product within the applica-
ble legal guarantee provisions. This guarantee is limited to damage that can be shown
to have resulted from normal use and obvious material or manufacturing defects. In
such cases the manufacturer, in collaboration with the local distributor, will attempt
