8. Produktspezifikation
This chapter contains the specifications of CR7P transmitter and R7FS receiver.
8.1 Transmitter Specification CR7P
Model Type Cars, Boats
Channels 7
RF Frequency 2.4GHz ISM
2.4G Protocol ANT
Maximum Power <20dBm
（
e.i.r.p.) (EU)
Reception Sensitivity ≤-99dBm
Channel Resolution 1024
Low Voltage Warning YES
Input power 4-9V/DC
Battery 1.5AA*4/2S Lipo
（
JST
）
Data Output Type-C Interface
Charging Interface NO
Antenna Type
Built-in single coaxial cable antenna
Display Mode 128*64 LCD
（
Black and white dot matrix screen
）
Online Update Absima Assistant Update
Distance ≥300m
（
Ground
）
Working Current About 110mA/6V
Temperature Range -10
℃
~+60
℃
Humidity Range
20-90%
Size 136.4*111.8*197.5mm
Weight 305g
Certification CE
，
FCC ID
：
N4ZG7P00
