Abus TVAC26030 - Page 36

13
Control layout DVR
PTZ menu
You can enter the PTZ menu by pressing the
IRIS button while you have a full screen
camera and then pressing the OK button or
the button on the joystick
Camera in full screen - IRIS- - OK/button on
joystick
Multi/Single view
With the FOCUS- button you can switch
between the different views
Preset
You recall presets by pressing the preset
number and then the PRESET button
Patrol
Preset 35 => Tour 1
Preset 36 => Tour 2
Preset 37 => Tour 3
Preset 38 => Tour 4
Cameras Change channel
By pressing the buttons 1-9 you can switch
between the different camera channels
Zoom
You can use the zoom by turning the joystick
or with the Zoom+/Zoom- buttons
Focus
You can adjust the focus using the
Focus+/Focus- buttons
Control layout NVR (Firmware 4.x)
PTZ menu
Enter the PTZ menu by pressing the IRIS
button while the camera is in full screen mode
and then pressing the OK button or the
button on the joystick
Camera in full screen - IRIS- - OK/button on
joystick
Multi/Single view
With the FOCUS- button you can switch
between the different views
Preset
You recall presets by pressing the preset
number and then the PRESET button
Patrol
To recall the Patrol press 35-38 and then press
PRESET
Preset 35 => Tour 1
Preset 36 => Tour 2
Preset 37 => Tour 3
Preset 38 => Tour 4
Change camera channel
By pressing the keys 1-9 you can switch
between the different channels
Zoom
You can use the zoom by turning the joystick
or with the Zoom+/Zoom- buttons
Focus
You can adjust the focus using the
Focus+/Focus- buttons
